- Наличие: Есть в наличии
- Код товара: 6996-0001
- Артикул: QRN-1610S
- 16CH,
- Max. 8MP resolution camera supported,
- H.265/ H.264/ MJPEG,
- 128Mbps network camera recording,
- WiseStream support,
- Plug & play by 16 PoE ports,
- Max. 2HDD,
- HDMI / VGA local monitor display,
- P2P service (QR code connect) support
Display Video Inputs Up to 16 channels Video Resolution CIF to 8 MP Protocols Wisenet, ONVIF Profile S Local Display HDMI/VGA Multi-Screen Display Local Monitor: 1, 2H, 2V, 3V, 4, 6, 8, 9, 13, 16, Auto Sequence Web: 1, 4, 9, 16, Auto Sequence Resolution Live Local Monitor Performance: 8 MP at 60 fps 5 MP at 90 fps 3 MP at 120 fps 2 MP at 240 fps 720p at 480 fps D1 at 480 fps Operating System OS Embedded Linux Recording Compression H.265, H.264, MJPEG Bandwidth Recording: Up to 128 Mb/s Recording Resolution CIF to 8 MP Recording Modes Manual, Schedule (Continuous/Event), Event (Pre/Post) Event Triggers 4 x Alarm Inputs, Video Loss, Camera Event (Sensor, Motion Detection, Video Analytics, Defocus) Event Actions Email, PTZ Preset, Alarm Out, Buzzer, Monitor Out Search & Playback Bandwidth 32 Mb/s (8 Channels Simultaneously) Number of Simultaneous Users 3 (1 Local, 3 Remote) Search Modes Date & Time (Calendar), Event Log List, Text Search (POS), ARB Search, Smart Search (Virtual Line with Direction, Enter/Exit) Playback Capability Local: Up to 8 Channels Network: Up to 16 Channels Resolution CIF to 8 MP Playback Control Fast/Slow Forward or Backward, Move One Step Up/Down Storage HDD Capacity 2 x HDD Bays, Up to 6 TB per HDD HDDs Available Separately Backup File Formats Backup/Executable File (USB), JPG/AVI (Web, CMS) Built-in Backup Functions Multi-Channel Play (Up to 16 Channels), Date-Time/Title Display Sensor I/O 4 x Inputs 2 x Outputs (NO, NO/NC) Audio I/O 16-Channel Input (Network) 1 x RCA Line Output Audio Compression G.711, G.726, AAC (16/48 kHz) Audio Communication 2-Way Network Protocols TCP/IP, UDP/IP, RTP (UDP), RTP (TCP), RTSP, NTP, HTTP, DHCP (Server, Client), PPPoE, SMTP, ICMP, IGMP, ARP, DNS, DDNS, UPnP, HTTPS, SNMP, ONVIF (Profile S), SUNAPI (Server, Client) DDNS Hanwha DDNS Bandwidth 128 Mb/s Max. Remote Users Search: 3 Live Unicast: 10 Live Multicast: 20 IP IPv4, IPv6 Security User Access Log, IP Address Filtering, 802.1x Authentication, Encryption Languages GUI/Web: English, French, German, Italian, Spanish, Russian, Turkish, Polish, Dutch, Swedish, Czech, Portuguese, Danish, Romanian, Serbian, Croatian, Hungarian, Greek, Norwegian, Finnish, Korean, Chinese (Simplified), Japanese, and Thai OS Supported Windows 7, 8, 10 Mac OS X 10.9, 10.10, 10.11 Supported Web Browsers Non-Plugin Webviewer: Google Chrome 47, Microsoft Edge 20 Plugin Webviewer: Microsoft Internet Explorer 11, Apple Safari 9 (Mac OS X only) Viewer Software Type: SSM, Webviewer, SmartViewer, Wisenet Mobile CMS Support: SDK/CGI (SUNAPI) Functions Camera Setup Register: PnP, Manual Mode Setup Items: IP Address, Add Profile Edit, Bitrate, Compression, GOP, Quality, Camera Motion Detection Setup, Camera Video Setup (Simple Focus, Brightness/Contrast, Flip/Mirror, IRIS, WDR, D&N, SSNR, Shutter, SSDR, DIS), Fisheye Dewarping Setup, Hallway View Setup, Camera Webpage PoE Camera Control Monitor PoE Power Consumption, On/Off Control for Each PoE Camera, Remote Reset for Each PoE Camera Configuration Setup Wizard (Date/Time, Network, Auto Camera Configuration), P2P (QR Code) ARB Yes PTZ Control Via GUI, Webviewer 255 Presets Mobile OS Support OS: iOS and Android Protocol Support: RTP, RTSP, HTTP, CGI (SUNAPI) Live 16-Channel Control: Multi-Profile Support, Playback (4 Channels), Event Push Maximum Remote Users: 3 Search, 10 Live Unicast, 20 Live Multicast System Control Mouse, IR Remote Control, Web Interface Indicator LEDs 6 x LEDs: HDD Status, Alarm, Power, Record, Backup, Network Interface Ports 1 x VGA Video Output (1920 x 1080, 1280 x 720) 1 x HDMI Video Output (3840 x 2160, 1920 x 1080, 1280 x 720) 1 x RCA Audio Line Output 16 x 100 Mb/s PoE Ports 1 x 1 Gb/s WAN Port (Uplink to CMS) 4 x Alarm Inputs (Terminal Block) 2 x Alarm Outputs (Terminal Block) 2 x USB 2.0, Front 1 x USB 3.0, Rear 1 x Reset Switch 1 x VDC Power System Log List Up to 20,000 for Each System/Event Log Certifications Certifications and Compliance FCC, UL, CE, EAC Environmental Operating Temperature 32 to 104 F / 0 to 40 C Operating Humidity 20-85% RH Electrical Input Voltage 100 to 240 VAC +-10% Maximum Power Consumption With 2 x HDDs, PoE On: 158.2 W With 2 x HDDs, PoE Off: 34.6 W PoE Budget 100 W Physical Housing Material Metal Rack Height 1 RU Dimensions 14.56 x 1.73 x 12.59" / 37.0 x 4.4 x 32.0 cm Weight 6.15 lb / 2.79 kg, Without HDDs Packaging Info Package Weight 9.7 lb Box Dimensions (LxWxH) 20.5 x 16.7 x 7.0"
